Tubitak PEM fuel cell developments for every type military/commercial vehicles

[cabatli_53]

---

---

Battery tabletsdeveloped by Tubitak MAM (It contains %12-45 of total unit costs, %80 of total volume in system)



Membran electrot units



Fuel battery modul production



---------- Post added at 11:40 AM ---------- Previous post was at 11:40 AM ----------

Tests



---------- Post added at 11:41 AM ---------- Previous post was at 11:40 AM ----------

NiMH batteries for vehicles

288 Vdc Voltage and 9 Ah capacity...


NiMH batteries' cell (1.2V and 9.5Ah).



---------- Post added at 11:42 AM ---------- Previous post was at 11:41 AM ----------

U-214TN battery watch system under development in Tubitak..



TÜB?TAK Marmara Ara?t?rma Merkezi

-Fully Electrical Propulsion development program for a WArship...

http://www.mam.gov.tr/EE/projeler/deniz-sistemleri.html

Battery development program for domestic Aselsan Sonobuoys..

[cabatli_53]

Sodium Boron Hydride batteries for civilian/Military vehicles (100KW)



TÜB?TAK Marmara Ara?t?rma Merkezi

[cabatli_53]

Tubitak NiHM Battery modules and battery watch system produced for Ford Otosan and Inci AKU

[cabatli_53]

Turkish institues under the management of Tubitak has fully concantrated on development of Fuel batteries. Ford-Otosan has charged to provide the vehicles...





Arçelik-Tubitak collaboration has started development of electrical motors powered by domestic fuel cells...

[cabatli_53]

Tubitak has reached knowledge enough to supply batteries for even big trucks...

[cabatli_53]

A Turkish made Prototipe Hibrid Ford Transit powered with Tubitak batteries... It is ready for serial production...



The Turkish universities working on hinrid technologies...

[cabatli_53]

Tubitak MAM batteries developed for Ford Otosan, Tofas Fiat vehicles.




---------- Post added at 01:05 PM ---------- Previous post was at 01:05 PM ----------

Electronical control section of batteries developed by Tubitak.


It sets the electrical power amounts between batteries-engine in accordance with user needs...

Battery control unit


---------- Post added at 01:06 PM ---------- Previous post was at 01:05 PM ----------

Arcelik Tubitak-MAM Electrical Motor/BLDC drivers and specifications used in Ford Otosan, Tofas Fiat hibrid prototipe vehicles.

[cabatli_53]

Tubitak-Ford Transit Hybrid



Tofas Tubitak Doblo Hybrid



---------- Post added at 01:08 PM ---------- Previous post was at 01:07 PM ----------

There is 3 different defence industry program related with hybrid technology...

FNSS HYBRID IFV
Ministery of national defence(MSB) supported Hybrid IFV
Ministery of national defence (MSB) supported fully electrical warship programs.



FNSS Hybrid IFV work

[Abdi-Karim Elmi]

Good. More please. Im very interested.

[LegionnairE]

Cabatli_53, do you think we can develop fuel cells efficient enough to supply our future AIP submarines?

[Aeronaut]

Cabatli53: Please post details of that armored vehicle above.

[Targon]

Yeah, could it be design of new ifv ?

[Saithan]

but why NiMH, I thought Li-ON was better. Is it because we don't have the raw materials in Turkey. Any information on Recycling the NiMH for reuse ?

[Axa-]

Why are you always providing so much info and details, dost var düsman var bak seni uyariyorum boyle devam edersen ilgili kurumlara haber edebilirim.

[Targon]

---

---

İnternet ortamında paylaşılmamış olsa bu adam bu resimleri nerden bulsun.
